Main Technical Parameters Table

product name

vacuum sweeper

gross mass （Kg）

18000

Rated load capacity (kg)

6170、6105

curb weight （Kg）

11700

Maximum number of passengers in the cab (people)

2,3

Angle of approach/angle of departure (°)

17/14

Axial Load (Kg)

6500/11500

product model

CLW5180TXCD6

outline dimension （mm）

7100,7250,7500,7800,8000,8330 ×2480×3085

Front/Side Suspension (mm)

1400/1930,1400/1900,1430/1900

Maximum Speed (Km/h)

89

Minimum ground clearance (mm)

180

Garbage Bin Capacity (m³)

8.1

Chassis Model

DFH1180EX8

Chassis Name

truck chassis

brand name

Dongfeng Brand

manufacturing enterprise

Dongfeng Commercial Vehicle Co., Ltd.

number of axles

2

Number of Tires

6

wheel base （mm）

3800,3950,4200,4500,4700,5000,5300,5800,5600

tyre size

10.00R20 18PR,275/80R22.5 18PR

Number of steel plate spring springs

7/9+6,8/10+8,8/9+6,11/10 +8

front gauge （mm）

1876,1896,1920,1950,1914,1934,1980,2000,1815

Rear wheelbase (mm)

1820,1860,1800

Fuel Types

diesel oil

Emission standards based on established criteria

GB3847-2005, GB17691-2018 – National Standard Grade VI

Scanning Width (m)

≥3.4

Scanning Speed (km/h)

3～15

Cleaning Speed (km/h)

15～25

Scanning Capacity (m²/h)

51000

Maximum Inhaled Particle Size (mm)

110

Garbage bin discharge angle (°)

≥45

Maximum Speed (km/h)

90

Ascent Slope (%):

≥20

Braking distance (at full load, 30 km/h) (m)

≤10

Minimum turning diameter (m)

≤19

Fuel consumption (L/100 km)

21.5

Fuel consumption for cleaning operations (at an average cleaning speed of 15 km/h): (L/h)

≤14.0

Fuel consumption for cleaning operations (at an average cleaning speed of 15 km/h): (L/10,000 m²)

≤3.4
