Main Technical Parameters Table

Full Vehicle Model

CL5120TXS6GH

Cleaning Operation Speed (km/h)

15-20

Chassis Model

EQ1125SJ8CDC

Maximum Cleaning Capacity (m²/h)

38000

effluent standard

GB3847-2005, GB17691-2018 National Standard Grade VI

Material density (g/cm³)

2

Main Engine Model

Cloud-based models: D25TCIF1, Yuchai YCY30165-60 (optional)

Material suction mass (kg)

1.5

Main Engine Horsepower (Ps)

Yunnei 150, Yuchai 165

Maximum suction particle size (mm)

≥100

Main Engine Displacement (ml)

Yunnei 2499, Yuchai 2970

Garbage bin dumping angle (°)

≥30

Secondary Engine Model

B140 33 (Dongfeng Cummins)

Scanning Efficiency

≥96%

Auxiliary Engine Power (kW)

102

Work Noise (dB)

<88, compliant with GB7258 standard

Auxiliary Engine Power (Ps)

140

Scan Configuration

Central-mounted dual scanning discs, driven by a hydraulic motor with adjustable speed

Secondary Engine Displacement (ml)

3200

Scanning expansion diameter (mm)

φ800-900

External Dimensions (Length × Width × Height) (mm)

7000×2200×2700

Scanning motor speed (r/min)

140

wheel base （mm）

3800

Scanning Disk Inclination

Anterior tilt: 5°–15°; lateral tilt: 5°–10°

tyre size

245/70R19.5、8.25R20

Nozzle Structure

Double-suction wide nozzle with hydraulic floating mechanism and spring suspension, featuring 8 built-in high-pressure nozzles

Maximum Total Mass (kg)

11995

Straw diameter (mm)

φ180

Preparation Mass (kg)

7400

Straw Brands

NORRES

Rated load capacity (kg)

440

Walking wheel bearing

SKF (Skifer)

Clear Tank Volume (m³)

4 (Stainless steel)

Walking Wheel Outer Ring

Stellana

Garbage Bin Capacity (m³)

5 (stainless steel)

Nozzle clearance from ground (mm)

5～8

Scanning Width (mm)

2800-3200

Nozzle and straw wind speed (m/s)

50~65

Scavenging Speed (km/h)

3-15

Nozzle negative pressure (mmH₂O)

380
