Main Technical Parameters Table

Product Brand

Cheng Liwei Brand

Maximum Total Mass (kg)

11995

Full Vehicle Model

CLW5120TXC6SL

Preparation Mass (kg)

6400

wheel base （mm）

3800

Rated load capacity (kg)

5400

engine type

D25TCIF1 (Yunnei); YCY30165-60 (Yuchai)

Water Tank Capacity (m³)

2

effluent standard

National VI standard, diesel engine

Garbage Bin Capacity (m³)

5

Engine Power (kW)

110、121

Maximum Cleaning Width (m)

2.8

Auxiliary Engine Power (kW)

64 (87 horsepower)

Scanning Speed (km/h)

5-20

External Dimensions (Length × Width × Height) (mm)

7150×2230、2300×2650、2700

Cleaning Speed (km/h)

15-20

Front Suspension / Rear Suspension (mm)

1130/2220

Maximum Cleaning Capacity (m²/h)

36000

Nozzle Structure

Back-mounted wide-nozzle with built-in rolling brush, hydraulic lifting + hydraulic floating mechanism

Side Configuration

Bilateral sweeping to collect debris and expand the operational area

Box Material

High-quality carbon steel, with 3 mm side plates and 4 mm base plates; the entire edge is folded and seamlessly welded.

Spray System

The electromagnetic diaphragm pump drives the tail spray rod to achieve dust suppression on road surfaces.

Filter cartridge Configuration

The new membrane filter cartridge, paired with an air-pulse cleaning system, offers convenient maintenance.

control monitor unit

Rearview monitoring camera providing real-time imaging in the cab

Control System

The CAN bus features integrated modular control, with a large cockpit display providing real-time monitoring of auxiliary engine speed, water temperature, and operating conditions.

emergency device

Manual pump emergency system: capable of lifting the trash bin for maintenance when the auxiliary unit is shut down.

Hydraulic component

The Hypris electromagnetic valve assembly can control the operation of mechanisms such as the sweeping disc, suction cup, and trash bin.

mode of operation

PLC integrated control with one-click start/stop and multiple modes for easy operation

Transmission Component

Automatic clutch reduces start-stop impact on the equipment, offering wear resistance and low consumption.

Maintenance Requirements

The main and auxiliary engines share a common fuel tank, with the fuel filter element being replaced periodically.

fan

High-power, maintenance-free centrifugal fan

After-sales Service Policy

Free repairs for non-human-induced faults within one year; dedicated personnel provide vehicle testing and training; nationwide warranty coverage.
