Main Technical Parameters Table

Full Vehicle Model

CL5180TXSD6GH

Installation location for dust removal and control systems

Left, Right, and Front Scanning

Chassis Model

DFH1180EX8

Vacuum cleaner installation location

Inside the suction port of the suction cup

Maximum Total Mass (kg)

18000

Control Type

Electronic Control, One-Click Operation

Preparation Mass (kg)

11730

Hydraulic System Type

Open, electrically powered centralized control system

Rated load capacity (kg)

6075

Hydraulic System Components

Gear pump, cycloidal motor, hydraulic cylinder, solenoid valve, integrated block, high-pressure pump

wheel base （mm）

5000

Epicycloid Motor

Liwoma Motor / Lido Motor

Tire Type

10.00R20 18PR

geared oil pump

Shiyan Changshun

Number of Tires

7 (including 1 spare tire)

hydraulic jack

Hypris

front gauge （mm）

1914

Hydraulic cylinder seal

Taiwan Dingji

Rear wheelbase (mm)

1820

Hydraulic Oil Pipeline

Da Hang

Rated Capacity (People)

3

Electromagnetic Valve Assembly

Hypris/Delta

Front Suspension / Rear Suspension (mm)

1430/2120

Earthquake-resistant pressure gauge

Chengdu Tianwei, Hangzhou, Tianjin

approach angle （°）

17

Return Oil Filter

Well-known domestic brands

departure angle （°）

12

System Overpressure (MPa)

10-12

Ground Height (mm)

400、340

Hydraulic Oil Tank Volume (L)

≥60

effluent standard

GB3847-2005, GB17691-2018 National Standard Grade VI

Chassis Circuit Voltage (V)

24

External Dimensions (Length × Width × Height) (mm)

8550×2480×3130

Working Device Voltage (V)

12

Main Engine Model

Cummins B6.2NS6B230

Electrical Control Box Configuration

Auxiliary engine tachometer, water temperature gauge, oil temperature alarm, operation switch

Main Engine Horsepower (Ps)

230

Control Switch Brand

Shanghai Schneider

Main Engine Displacement (ml)

6200

PLC brand

Bai Qiaofu

Secondary Engine Model

B170 33: Cummins 170-horsepower turbocharged model

Circuit breaker Brands

Haiger

Auxiliary Engine Power (kW)

125

Battery Specifications

12 V – 140 Ah (2 units connected in parallel)

Auxiliary Engine Power (Ps)

170

Fan Type

Grade 9.0 Maintenance-Free Centrifugal Fan

Secondary Engine Displacement (ml)

5900

Fan Power Transmission Method

Auxiliary engine + clutch + 4 toothed, high-temperature resistant A-belts

Clear Tank Volume (m³)

9

Fan Belt Brands

Zhejiang Three-Dimensional

Garbage Bin Capacity (m³)

7 (stainless steel)

Fan rated speed (r/min)

2000

Scanning Width (mm)

3000-3500

automatic clutch

centrifugal

Scavenging Speed (km/h)

3-15

Fan Airflow (m³/h)

12000~23000

Cleaning Operation Speed (km/h)

15-20

Scan Structure

The sides of the frame are adjustable in height and extend outward for vertical sweeping, driven by a hydraulic motor with adjustable rotational speed.

Maximum Cleaning Capacity (m²/h)

Approximately 50,000

Scan Disk Accessories

Scanning bracket, hydraulic cylinder, oil pipe, connecting rod, adjustment rod, hydraulic motor

Material density (g/cm³)

2

Scanning expansion diameter (mm)

φ800-900

Mass of a single sample for aspiration (kg)

1.5

Scanning Count

2

Maximum suction particle size (mm)

≥100

Brush count per disc

22

Garbage bin dumping angle (°)

≥30

Scanning Disk Inclination

Anterior tilt: 5°–15°; lateral tilt: 5°–10°

Scanning Efficiency

≥96%

Nozzle Structure

Double-suction nozzle with wide intake; hydraulic + spring floating suspension; equipped with 8 built-in high-pressure nozzles

Work Noise (dB)

<88, compliant with GB7258 standard

Straw diameter (mm)

φ180

Driven Type

4×2 rear-wheel drive

Straw Brands

NORRES

Suspension Type

plate spring

Walking wheel bearing

SKF (Skifer)

Number of steel plate springs (front/posterior)

8/10+8

Walking Wheel Outer Ring

Stellana

Braking Type

Double-circuit pneumatic brake, drum type

Nozzle and straw wind speed (m/s)

50~65

Braking distance at full load at 30 km/h (m)

≤10

Nozzle negative pressure (mmH₂O)

380

Maximum Speed (km/h)

89

Nozzle rigidity clearance from ground (mm)

5~8

Minimum turning radius (m)

9.5

Additional Configuration

Reverse parking voice alarm, rear electronic control unit, manual emergency lifting system

clutch

Single-piece dry diaphragm spring clutch, hydraulically operated

Key Features

Complementing the Cummins auxiliary unit is a GP-36 high-pressure pump with a maximum air pressure of 10 MPa; equipped with a water tank capacity of 9 m³ and a waste bin capacity of 7 m³ (both made of stainless steel); the unit features a high-pressure self-cleaning device.

transmission

Fast Eight-Speed Transmission

Work Mode

Various modes including full wash sweep, right-side wash sweep, full sweep, and right-side sweep

Fuel consumption per 100 kilometers (L)

≤14

Function Configuration

Road surface cleaning, sweeping, curb washing, low-pressure flushing, spray dust removal, 15-meter high-pressure drum washing

Daily Operation Fuel Consumption (L)

≤8

Box Material

Side plate: 3 mm; bottom plate: 4 mm; fully seamless welded with corrosion resistance.

Fuel consumption per 10,000 square meters of work area (L)

≤3

Auxiliary Engine Idling (r/min)

750~790

Dust suppression and water spraying method

Low-pressure mist

Maximum RPM of the auxiliary engine (r/min)

2400

High-pressure Water Pump Brands

GTM

Maintenance Requirements

The main and auxiliary engines share a common fuel tank, with the fuel filter element being replaced periodically.

High-voltage system components

High-pressure pump, water filter, piping system, stainless steel spray frame, high-pressure nozzle

After-sales Service Policy

Comprehensive performance testing under all driving conditions; nationwide warranty coverage; free repairs for non-human-induced faults for one year.
