Main Technical Parameters Table

Full Vehicle Model

CLW5180TXSD6

Chassis Model

DFH1180EX8

wheel base （mm）

5000

weight distribution

Front axle: 6500 kg / Rear axle: 11500 kg

Approach/Departure Angle

18° / 24°

Main Engine Model

Longqing Power DDi47E210-60 – a National VI standard diesel engine.

Main Engine Power (kW)

154

External Dimensions (Length × Width × Height) (mm)

8550×2480×3130

Front/Side Suspension (mm)

1400/2150、1430/2120

Water tank volume (m³)

9

Garbage Bin Capacity (m³)

7

Auxiliary Engine

Cummins 170 horsepower

curb weight （kg）

11800

Maximum Total Mass (kg)

18000

Rated load capacity (kg)

6005

Maximum Cleaning Width (m)

3.5

Maximum Cleaning Capacity (m²/h)

60000

Scanning Speed (km/h)

5-20

Cleaning Speed (km/h)

15-20

maximum speed

89km/h

Maximum diameter of inhalable particulate matter

Φ120mm

engine displacement

6200mL

Rated Power / Horsepower

154 kW (210 HP), peak torque: 780 N·m

gear-box

Fast 8JS95E-C – 8-speed manual transmission

tyre size

10.00R20 18PR steel wire vacuum tires, for both rear wheels

Number of steel plate spring springs

First 8 pieces / Last 10 + 8 reinforced leaf springs

Fuel tank volume

160L metal corrosion-resistant fuel tank
