Exterior Design

(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle
(600 liters) Electric three-wheel cleaning vehicle

Configuration Parameters

Vehicle Chassis Engine Volume Boundary Distance
Note: While we have made every effort to ensure the accuracy of this product description based on currently available information, please note that vehicle specifications, configurations, materials, colors, and other details are subject to change at any time. Therefore, this product description is for reference only; the actual appearance, configuration, and color of the vehicle shall be determined by the physical vehicle at the time of sale.

Key features:
◆ Chassis: Uses the chassis of Zongshen heavy-duty three-wheeler electric vehicle, with nationwide warranty and easy maintenance. Equipped with a 60V 1200W 24-pole walking motor and a 45AH dry maintenance-free battery, ensuring strong power output. The frame adopts a double-beam structure, with mechanical high and low speed adjustment, and strong climbing ability. Equipped with larger tires and shock absorbers, capable of easily handling heavy-duty work conditions.
◆ Box: Built-in dedicated plastic water tank, permanently rust-proof, with a capacity of 600 liters, capable of normal flushing for 45 minutes. Carbon steel for painting or stainless steel hinged box, beautiful and convenient for maintenance.
◆ Cleaning pump unit: Honda engine equipped with an Italian water pump. The engine uses electronic ignition, with an added 35-liter large-capacity fuel tank. The water pump outputs 275 kilograms of pressure, with strong cleaning ability.
◆ Gun barrel accessories: Comes with a 15-meter high-pressure water pipe automatic reel, and a high-pressure water gun.
◆ Core functions: The vehicle head is equipped with left and right adjustable flushing devices, providing the best solution for automated cleaning and maintenance on sidewalks and slow lanes.



Vehicle configuration

Washing vehicle model

CF600GQX

Overall vehicle dimensions (length × width × height)

3000×1100×1500

chassis

Zongshen brand

Walking motor

60V-1200W 24tubes

battery

Tianeng 45Ah dry-type maintenance-free battery

endurance mileage

50 km

tap position

With a variable-speed and hill-climbing gear

water tank

600-liter plastic water tank, permanently rust-proof

engine

Original Honda imported engine

start method

Electronic ignition + Manual

capacity of tank

35 L

high-pressure pump

ItalyAR

working pressure

275 bar

pump flow

15L/min

fan nozzle

0/15/25/40degrees

High-pressure drum

15 m


Product Details

Product Detail 1 Product Detail 2 Product Detail 3 Product Detail 4 Product Detail 5 Product Detail 6 Product Detail 7 Product Detail 8 Product Detail 9 Product Detail 10
Product Detail 1

Contact us for a free consultation!
