Tianjin National VI chassis with a wheelbase of 4700 mm, model: DFH1180EX8, gross weight 18,000 kg;
Tank: 14.5 cubic meters in capacity, with freely adjustable volumes for clean water and sewage tanks, allowing interconnection between the two; tank wall thickness of 6 mm, with stainless steel plates installed at the bottom of the suction section. The top of the suction tank features a concrete inlet, and the tank is equipped with a platform on its upper part.
High-pressure pump: A 250L high-flow high-pressure pump capable of clearing municipal pipelines up to 800–1300 mm in diameter.
Suction unit: 2BE-204 water ring vacuum pump, flow rate: 1300 m³/h, vertical suction depth up to 10 meters, horizontal suction distance not less than 50 meters. (Optional: Italian BP imported rotary vane vacuum pump—vertical suction depth up to 10 meters, horizontal suction distance not less than 50 meters; or Hangzhou Weilong vacuum pump.)
Filter: Custom oversized stainless steel filter;
Extra-large reel: rear-mounted hydraulic cleaning reel with 160-degree hydraulic rotation. (Hydraulic control allows left/right positioning, reeling in and out the hose.) Can accommodate 80–100 meters of high-pressure hose.
Standard configuration includes one 4.5 kg grenade nozzle, one diamond nozzle, one mushroom nozzle, and one homemade cleaning spray gun (optional imported ceramic special nozzle available);
PVC 102mm vacuum sewage pipe, 8 meters;
The rear head can be optionally equipped with a round-hole level sight glass.
