Tianjin Guo Li sixth-generation chassis has an axle spacing of 4700mm. Model: DFH1180EX8. Total weight: 18000KG.
Tank: Volume 15 cubic meters. The capacity of the water tank and the sewage tank can be freely divided, and the water and sewage can be intercommunicated. The thickness of the tank is 6mm. The bottom of the sewage suction part is covered with stainless steel plate. The top of the sewage suction tank is a cement filling opening, and the top of the tank is equipped with a platform.
High-pressure pump: The 250L high-flow pressure pump can clear municipal pipelines within a length of 800 - 1300mm.
Sewage suction section: 2BE-204 water ring vacuum pump, flow rate: 1300 m³/h, vertical suction depth can reach 10 meters, horizontal suction distance is not less than 50 meters. (Optional Italian BP imported diaphragm vacuum suction pump: vertical suction depth can reach 10m, horizontal suction distance is not less than 50m. Or Hangzhou Weilong vacuum pump.)
Filter: Customized oversized stainless steel filter;
Super large reel: Rear-mounted hydraulic cleaning reel, capable of 160-degree hydraulic rotation. (Hydraulic control for reeling in/out and positioning of the reel) Can wind up to 80-100 meters of high-pressure hose.
Standard equipment includes 1 4.5KG grenade spray head, 1 diamond-shaped spray head, 1 mushroom-shaped spray head, and 1 homemade cleaning spray gun (optional to be equipped with imported ceramic special spray heads).
PVC 102mm

Type vacuum sewage pipe, length 8 meters；
The rear head can be equipped with a circular hole liquid level indicator.
