Upper garment configuration:
The tank is divided into two layers: the lower layer is a collection box for wastewater after solid-liquid separation. The two ends of the wastewater tank are higher, while the middle is lower. The lowest end has an outlet to ensure that the wastewater is discharged cleanly. The feed opening and the rear door are hydraulically sealed. The feed mechanism is of the lifting lever type. The tank has a lifting and dump function, making the excretion more thorough and clean. In addition to the simple transportation and collection, the kitchen waste truck can also be equipped with a solid-liquid separation device, suction cleaning function, and tank cleaning function, etc. The hydraulic system consists of pumps, hydraulic valves, sequence valves, and various types of hydraulic cylinders and high and low pressure pipelines. Key components can be selected as original imported products to ensure the reliable and safe operation of the product. The distance between the garbage input port and the push plate is sufficient. The push plate and the inner surface of the tank are equipped with sealing devices to prevent the spillage of kitchen waste during the input process and the separation process onto the rear side of the push plate.

Chengli Kitchen Waste Collection Vehicle Operating Method:
Firstly, the barrel-like “waste water” is slowly conveyed upwards by the conveyor belt of the vehicle, and then poured into the vehicle (the vehicle can be divided into a body and a tank). The dumped garbage is then compressed by a powerful push plate.
Then, solid-liquid separation occurs. The separated liquid enters the sewage tank at the bottom of the container, while the solid waste is compressed and stored in the container, reducing its volume. This process repeats until the container is full, and then it is sent to the kitchen waste resource optimization processing plant.

Selection of configuration:
Solid-liquid separation device: The separation device is equipped with a pushing head, which can push the garbage from the front of the tank to the rear of the tank. The separation screen plate is made of 304 stainless steel.
2. Vacuum cleaning function: In cases where there is a large garbage storage tank, the vacuum cleaning device can be used to directly suck the catering waste into the tank.
3. Internal heating device: Diesel burner, stainless steel combustion chamber, equipped with high and low temperature settings for automatic ignition and extinguishing heating; suitable for cold regions in winter, preventing the kitchen waste in the tank from solidifying due to excessively low temperature.
